Spearhead for '15-23 Road Glide | Harley Handlebars
KST Kustoms Spearhead for 2015-2023 Harley Davidson Road Glide
KST Kustoms Spearhead for 2015-2023 Harley Davidson Road Glide
Spearhead for '15-23 Road Glide | Harley Handlebars
Spearhead for '15-23 Road Glide | Harley Handlebars
Spearhead for '15-23 Road Glide | Harley Handlebars
Spearhead for '15-23 Road Glide | Harley Handlebars
1/7

Spearhead for '15-23 Road Glide | Harley Handlebars

$455.00
The Spearhead Series gives Harley riders a sharper handlebar style with more room to dial in their fit. Its signature pointed bend gives Road Glide, Softail, Dyna, and Sportster builds a stronger, more aggressive profile, while the adjustable design lets riders fine-tune hand position and pullback for a more comfortable ride. It's a strong fit for riders who like the look of a T-bar-inspired setup but want a handlebar that still works naturally with their Harley's touring or cruiser layout.
10
12
14
Polished
High Gloss Black
1.25"
SELECTED:

PRODUCT INFORMATION

-Designed for the 2015-2023 Harley Davidson Road Glides including standard, special, CVO and limited. Will not fit the 23 CVO Model

This 3 piece, fully adjustable system gives you the versatility to customize the look and comfort of your Harley Davidson Motorcycle. The Vanguard Collection gives you the benefits of an adjustable handlebar, without sacrificing the looks of a traditional handlebar

These handlebars are 1.5" OD which gives you a very strong and robust look.

Our hand polished stainless steel finish gives the appearance of chrome but with the durability of stainless. High Gloss black powder coating is from the same supplier used by Harley Davidson

Super Easy to internally wire- No more headache of running wires inside bars.

Clamping surface is knurled to ensure a solid and strong hold with no rotation in the clamp.

The Spearhead style features our signature custom point, often referred to as a meat hook, with a slight radius in the rise.

Base clamp is 13" outside to outside with a 1.25" diameter

Click here to see overall widths

Stock Road Glide Handlebars are 9" tall and 11" tall on the Limited models

Can be purchased pre-wired Pre-Wired Bundle

-2021-2023 Road Glide: 10 & 12" tall bars can be installed without replacing your brake and clutch and without extending your electrical system. 14" will require extending the clutch cable. Clutch Extension part# 109812

-2015-2020 Road Glide: 10, 12", and 14" tall bars can be installed without replacing your brake and clutch and without extending your electrical.

 If you need/want to replace your cables, we recommend Dennis Kirk or J&P Cycles. They carry a couple of brands that offer all in one box kits based on your model year and handlebar height

If you have made changes to the stock riser, please let us know so we can make sure you receive the correct diameter clamping section

Patent Pending

NARROW, CONTROLLED FEEL:

Designed for Harley-Davidson 2023 CVO and 2024-2026 Street Glide models.

This handlebar comes up and back toward the rider 4 extra inches compared to stock. The wrist angle is ergonomically redesigned to place your wrist in a more neutral position and help prevent rider fatigue.

Manufactured from 1.25-inch T304 ornamental-grade stainless steel and CNC mandrel bent.

Our hand-polished stainless steel finish gives the appearance of chrome with the durability of stainless steel. Our high-gloss black powder coating is produced by the same supplier used by Harley-Davidson.

Notched and slotted for internal wiring and throttle by wire. Will also fit non-throttle-by-wire models and accepts heated grips.

Specs: 33 inches wide tip to tip, 33-degree wrist angle, and +4 inches back to the rider.

Can be purchased with our 2024-2026 Pre-Wired Bundle.

2023 CVO and 2024-2026 model years: you will need to replace the upper clutch cable, but the brake and electrical will be fine at stock length.

PRODUCT VIDEOS

Follow the full install process for 2024-2026 Street Glide models and see how KST handlebars are fitted for a clean, proper installation.

Get a fitment overview for 2024-2026 Road Glide and Street Glide models, including the latest bike changes and what they mean for handlebar setup.
